2.4GHz frequency

2.4GHz ~ 2.484GHz

2.4GHz WIFI protocol

802.11 b / g / n /ax

5GHz frequency

5.150GHz～5.850GHz

5GHz WIFI protocol

802.11 a / n / ac /ax

6E frequency

5.925GHz～7.125GHz

6E WIFI protocol

802.11 ax

2.4GHz Antenna

External omni antenna: 2*2.4GHz: 6dBi

5GHz Antenna

External omni antenna: 2*5GHz: 6dBi

6E Antenna

External omni antenna: 2*6GHz: 6dBi

Max rate

2.4GHz provides a maximum access rate of 574Mbps, 5GHz provides a maximum access rate of 4804Mbps, and 6E provides a maximum access rate of 2882Mbps.

2.4GHz EVM

802.11b:≤-10 dB ；802.11g: ≤-25 dB ；802.11n:≤-28 dB；802.11ax:≤-35 dB

5GHz EVM

802.11a:≤-25 dB ；802.11n: ≤-28 dB ；802.11ac:≤-32 dB；802.11ax:≤-35 dB

6GHz EVM

802.11ax:≤-35 dB

ppm

±20ppm

WAN

1*10/100/1000/2500Mbps WAN, support POE 48V

Reset

Press and hold for 6-10 seconds to restore factory default configuration

Indicator

WAN

Power supply

PoE 802.3at，DC2.0 12V/3A

Max power consumption

<26W

Size

295mm×231mm×80mm

Weight

2.2kg

Temperature

Working: -20°C to 55°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)

ESD

Air:±8K, Touch:±4K

Electrical Surge

Common Mode: 2K, Differential Mode: 1K
