Specifications
Model	Q3000
CPU	IPQ5018 +QCN6102
Flash	SPI NOR 8MB SPI NAND 128MB
DDR3	External 512MB*1
2.4G Frequency	2.4GHz – 2.484GHz
2.4G Protocol	802.11 b / g / n/ac /ax
5G Frequency	5.150GHz～5.825GHz
5G Protocol	802.11 a / n / ac /ax
2.4G Antenna	2*4dBi
5G Antenna	2*4dBi
Data Rate	2.4G: 574Mbps; 5G: 2402Mbps
2.4G TX Power	802.11b	11M	24±2dBm	1M	24±2dBm
	802.11g	54M	21±2dBm	6M	23±2dBm
	802.11n HT20	MCS7	20±2dBm	MCS0	22±2dBm
	802.11n HT40	MCS7	20±2dBm	MCS0	22±2dBm
	802.11ax HE20	MCS11	18±2dBm	MCS0	22±2dBm
	802.11ax HE40	MCS11	18±2dBm	MCS0	22±2dBm
5G TX Power	802.11a	54M	19±2dBm	6M	22±2dBm
	802.11n HT20	MCS7	18±2dBm	MCS0	21±2dBm
	802.11n HT40	MCS7	18±2dBm	MCS0	21±2dBm
	802.11ac VHT20	MCS9	17±2dBm	MCS0	21±2dBm
	802.11ac VHT40	MCS9	17±2dBm	MCS0	21±2dBm
	802.11ac VHT80	MCS9	17±2dBm	MCS0	21±2dBm
	802.11ax HE20	MCS11	17±2dBm	MCS0	21±2dBm
	802.11ax HE40	MCS11	17±2dBm	MCS0	21±2dBm
	802.11ax HE80	MCS11	17±2dBm	MCS0	21±2dBm
	802.11ax HE160	MCS11	17±2dBm	MCS0	21±2dBm
2.4G Receiving Sensitivity	802.11b	11M	-85dBm	1M	-90dBm
	802.11g	54M	-72dBm	6M	-90dBm
	802.11n HT20	MCS7	-70dBm	MCS0	-87dBm
	802.11n HT40	MCS7	-68dBm	MCS0	-85dBm
	802.11ax HE20	MCS11	-60dBm	MCS0	-83dBm
	802.11ax HE40	MCS11	-56dBm	MCS0	-83dBm
5G Receiving Sensitivity	802.11a	54M	-72dBm	6M	-92dBm
	802.11n HT20	MCS7	-70dBm	MCS0	-90dBm
	802.11n HT40	MCS7	-68dBm	MCS0	-88dBm
	802.11ac VHT20	MCS8	-70dBm	MCS0	-88dBm
	802.11ac VHT40	MCS9	-68dBm	MCS0	-88dBm
	802.11ac VHT80	MCS9	-58dBm	MCS0	-85dBm
	802.11ax HE20	MCS11	-62dBm	MCS0	-88dBm
	802.11ax HE40	MCS11	-58dBm	MCS0	-86dBm
	802.11ax HE80	MCS11	-55dBm	MCS0	-84dBm
	802.11ax HE160	MCS11	-51dBm	MCS0	-82dBm
2.4G EVM	802.11b:≤-10 dB ；802.11g: ≤-25 dB ；802.11n:≤-28 dB；802.11ax:≤-35 dB
5G EVM	802.11a:≤-25 dB ；802.11n: ≤-28 dB ；802.11ac:≤-32 dB；802.11ax:≤-35 dB
ppm	±20ppm
WAN	1*10/100/1000 RJ45,
LAN	3*LAN
SIM	2*Sim card slot ,1 Module
Reset	Reset to factory settings by pressing 6-10 seconds
Indicators	WAN, LAN, tricolor LED(sys-red, 2.4G-green, 5.8G-blue)
Power	DC2.0 12V 1.5A，PoE 802.3at
Max Power Consumption	< 16W
Weight	0.55kg
Temperature	Working: -10°C to 45°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)
ESD	Air:±8K, Touch:±4K
Electrical Surge	Common Mode: 2K, Differential Mode: 1K
5G module	RM520N (X62) -EU(EMEA/ APAC1 / Brazil) 5G NR: n1/3/5/7/8/20/28/38/40/41/71/75/76/77/78; LTE-FDD: B1/3/5/7/8/20/28/32/71; LTE-TDD: B38/40/41/42/43; WCDMA: B1/5/8 -GL 5G NR: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/71/75/76/77/78/79; LTE-FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/ 32/66/71; LTE-TDD: B34/38/39/40/41/42/43/48; LAA: B46; WCDMA: B1/2/4/5/8/19
