11AC Dual Band Super Slim Wall Mount AP-Products-Shenzhen Yunlink Technology Co., Ltd.©2023

Model	FAP812F
CPU	MT7628DAN+7613
Flash	SPI NOR 8MB
DDR3L	64MB
2.4G Frequency	2.4GHz ~ 2.484GHz
2.4G Protocol	802.11 b / g / n
5G Frequency	5.150GHz～5.850GHz
5G Protocol	802.11 a / n / ac
2.4G Antenna	2*2dBi
5G Antenna	2*2dBi
Data Rate	5G: 867Mbps 2.4G:300Mbps
2.4G TX Power	802.11b	11M	17±2dBm	1M	19±2dBm
	802.11g	54M	16±2dBm	6M	18±2dBm
	802.11n HT20	MCS7	15±2dBm	MCS0	17±2dBm
	802.11n HT40	MCS7	14±2dBm	MCS0	16±2dBm
5G TX Power	802.11a	54M	16±2dBm	6M	18±2dBm
	802.11n HT20	MCS7	15±2dBm	MCS0	17±2dBm
	802.11n HT40	MCS7	14±2dBm	MCS0	16±2dBm
	802.11ac HT80	MCS9	13±2dBm	MCS0	15±2dBm
2.4G Receiving Sensitivity	802.11b	11M	-82dBm	1M	-94dBm
	802.11g	54M	-72dBm	6M	-90dBm
	802.11n HT20	MCS7	-70dBm	MCS0	-88dBm
	802.11n HT40	MCS7	-68dBm	MCS0	-86dBm
5G Receiving Sensitivity	802.11a	54M	-72dBm	6M	-90dBm
	802.11n HT20	MCS7	-70dBm	MCS0	-88dBm
	802.11n HT40	MCS7	-68dBm	MCS0	-86dBm
	802.11ac HT80	MCS9	-58dBm	MCS0	-82dBm
2.4G EVM	802.11b: ≤-10 dB；802.11g: ≤-25 dB；802.11n: ≤-28dB
5G EVM	802.11a: ≤-25 dB ；802.11n: ≤-28 dB ；802.11ac: ≤-32 dB
ppm	±20ppm
WAN	1*10/100M WAN, support 48V POE
LAN	1*10/100M LAN
POE	802.3af
Reset	Reset to factory settings by pressing 6-10 seconds
Indicators	SYS
Max Power Consumption	<8W
ESD	Air:±8K, Touch:±6K
Electrical Surge	Common Mode: 1K, Differential Mode: 0.5K
Size	86mm86mm42.8mm
Weight	0.08kg
Temperature	Working: -10°C to 40°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)
